F250 SD vs 4x4 Off-Road Edition height ???

2.4K views 13 replies 7 participants last post by  Cj Ford
#1 ·
I just bought an F250 SD w/ 4x4 "Off-Road" sitckers on the rear.
Is this truck higher than a standard F250 SD ??

I am having trouble hooking up my trailer and loading the bed due to the height.

Can I lower it cheaply?
Here are some pics.
Rear:


Front:

#2 ·
you can get a drop hitch... as for the height i dunno i dont remember mine not being lifted, but i have a 4 inch lift and no trailer problems

#4 ·
There is no difference in stock ride hieght between a standard 250 and one that has the off-road package.

You can remove that 2 inch lift block from between the axle and leaf springs. Other then that no other way to cheaply lower the rear.

#6 ·
No problem, if you do remove those blocks. Please get new U-bolts. Also if you remove those blocks your truck will ride level instead of sloping towards the front.

#10 ·
The block in the rear of a F-250 and F-350 DRW are 2 inch but a F-350 SRW is a 3 3/4" block... Someone correct me if I am mistaken?

And to answer the question, You can just take the block out and level it and lower the rear...

The 4x4 Off-road was supposedly upgraded shocks and a fuel tank and transfer case skid plate I believe.

#11 ·
if anyone has done a lift and has a set of stock 2" blocks kicking around... Id be interested in them as mine sits about 1/2 in higher in the front then the rear, then with my trailer hooked up it sits lower in the rear making it look like its overloaded...

#12 ·
Exactly, my stock SD 4x4 had the lower blocks only from your first pic. When I added my 3" lift the extra blocks were added. Just remove the top blocks and replace the U bolts with some new ones.

#13 ·
Yours should have 2" blocks already correct? If so I would go with an add-a-leaf, you will also get slightly more weight capacity that way also.

#14 ·
if that was directed twards me I dont have blocks in the rear at all .. its a 2wd they didnt use rear blocks.. It had a factory rake till I put the front leveling spacers on .. then it sat almost perfectly level, it holds weight real well but id like it to sit level with the trailer hooked up ill need 1 1/2-2" to do that, my other option is air bags for when I have the trailer hooked up
