Finally got my stacks!! ~ PICS~

11517 Views 179 Replies 34 Participants Last post by TwinTurboStroker, Jan 13, 2009

Clay Henry

Discussion Starter · Jan 5, 2009 (Edited)

5

Perfection if i do say so myself.......
This bed kit is far and above anything you can buy IMO. I think i will start making these to sell.
Under the truck the 4" nipple down goes to a short piece (8") of flex pipe, then a hard pipe 90* bend to the straight piece running to the engine. Worked out very nice other than i had to widen out the hole in the bed (that pissed me off) because we mis measured something and to center the stax, we had to widen the hole to move it over 1/4"

Comments?

See less See more

1 - 20 of 180 Posts

6.0 p-stroke

· #2 · Jan 5, 2009

Very Nice!:nod::thumb:

taylorking

· #3 · Jan 5, 2009

those are definitely different looking, but simple enough :thumb:

they look great!

did u do the welding?

Clay Henry

Discussion Starter · #4 · Jan 5, 2009 (Edited)

3

More pics here http://www.powerstroke.org/forum/950181-post31.html

See less See more

taylorking

· #5 · Jan 5, 2009

now do us all a favor and wash that truck!

:hehe:

sea71

· #6 · Jan 5, 2009

Yeah I got a question - What kinda BB gun is that behind the TV?:hehe:

Nice clean look there. I take it that design was invented to coincide with a WVO tank somehow?

diesel_19

· #7 · Jan 5, 2009

looks good i definitly havent seen anyone do there bed kit like that before.

Clay Henry

Discussion Starter · #8 · Jan 5, 2009

taylorking said:
those are definitely different looking, but simple enough :thumb:

they look great!

did u do the welding?

Different? What do you mean?
I think the 5" pipe cut with 45s is so much cleaner looking than the 90* sweeps.

I helped a buddy do the welding...grinding...fitting...etc. Hes a welder/pipe fitter by trade so it was a walk in the park for him. He has all the tools which made it really easy.
The 4" pipe through the bed is saddle cut to the 5" header, offset centered to allow the stacks to be set back and in closer to the bed front...that was kinda tought to fab but it turned out great.

bigwhite7.3stroker

· #9 · Jan 5, 2009

Looks awesome

Clay Henry

Discussion Starter · #10 · Jan 5, 2009

taylorking said:
now do us all a favor and wash that truck!

:hehe:

Yeah its filthy...i knew someone would mention that :doh:

sea71 said:
Yeah I got a question - What kinda BB gun is that behind the TV?:hehe:

Nice clean look there. I take it that design was invented to coincide with a WVO tank somehow?

Its a Henry Lever action 22
No, has nothing to do with the vegi tank..i ordered a 60 gal tank, sold my 90 gal so there was room for the stax.

diesel_19 said:
looks good i definitly havent seen anyone do there bed kit like that before.

Me either, i like to be different. I may take it all out and have it powder coated black now.

taylorking

· #11 · Jan 5, 2009

CHenry said:
Different? What do you mean?
I think the 5" pipe cut with 45s is so much cleaner looking than the 90* sweeps.

I helped a buddy do the welding...grinding...fitting...etc. Hes a welder/pipe fitter by trade so it was a walk in the park for him. He has all the tools which made it really easy.
The 4" pipe through the bed is saddle cut to the 5" header, offset centered to allow the stacks to be set back and in closer to the bed front...that was kinda tought to fab but it turned out great.

im just sayin ive never seen any like it before, not that i dont like them...i think they look great man :nod:

ford_trck

· #12 · Jan 5, 2009

It's about time and holy crap there are a lot of people viewing this thread 19!

Clay Henry

Discussion Starter · #13 · Jan 5, 2009

ford_trck said:
It's about time and holy crap there are a lot of people viewing this thread 19!

I have a big following... :lol:

Heck this thread has been drawn out a few weeks now :doh:

breuer69

· #14 · Jan 5, 2009

Looks good its about time we got the pics.

[email protected] Automotive

· #15 · Jan 5, 2009

great pics bud... looks good

-Raul

MrJohnWayne

· #16 · Jan 5, 2009

Looks great Clay! Not as cool as mine, but still! :lol:

szyd

· #17 · Jan 5, 2009

Perfect everything is perfect size, placment, length.:thumb:

The way it is built you dont have to put mounts at the top of the bed?

03ccf350

· #18 · Jan 5, 2009

you know, i was never really a fan of stacks, but i like those. like was said, right height, size, and all that it looks real good CH. i have a cap but i would consider something like that.

maybe i could get them through the cap?? that would not look to dorky at all would it? :hehe:
clarence

Sawed Off

· #19 · Jan 5, 2009

very nice!

RC51

· #20 · Jan 5, 2009

They look good Clay!:thumb:

1 - 20 of 180 Posts
