Help! No start, no buzz

I'm working on a customers truck. Did an egr delete on it. Got it all back together and all it would do is crank. Good icp ect... No injector buzz. I had no ficm v until I started wiggling wires around on the injector harness. Then the injectors would start buzzing. After a ton of cranking and dieing it started. Went and drove it had a huge miss. The whole truck would shake when you lug it. And no power. Shut it off back at the shop. It started right up again. This morning. All it will do is crank. Have 48v ficm v but no buzz.? Help!!!


Sent from my iPhone using AutoGuide.com Free App


To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
[/URL]

[CENTER]2012 King Ranch
22k deleted at 1k
5" FLO-PRO
S&B Intake
Sinister Egr Delete
MiniMax/ SPE Tunes
466/953 on 37's
6" 4 link
37's on 22's
Bags and compressor
RBP mudflaps
transfer tank tool box.
9" 2" poly boss v blade
Should have kept my 6.0.....
2003kingranch is offline
Sponsored Links
Advertisement

post #2 of 11 Old 01-12-2013, 03:03 PM Thread Starter
Compression Ignition Addict

2003kingranch's Avatar

Join Date: Dec 2010
Location: IOWA
Posts: 2,542
Thanks: 0
Thanked 0 Times in 0 Posts
Mentioned: 0 Post(s)
Quoted: 0 Post(s)
Feedback Score: 0 reviews
Send a message via Skype™ to 2003kingranch
Got it to start. Ram great for 20 sec then just shut off. Now no injector buzz again


Sent from my iPhone using AutoGuide.com Free App


To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
[/URL]

[CENTER]2012 King Ranch
22k deleted at 1k
5" FLO-PRO
S&B Intake
Sinister Egr Delete
MiniMax/ SPE Tunes
466/953 on 37's
6" 4 link
37's on 22's
Bags and compressor
RBP mudflaps
transfer tank tool box.
9" 2" poly boss v blade
Should have kept my 6.0.....
2003kingranch is offline
post #3 of 11 Old 01-12-2013, 03:21 PM
WWW.COMPIGNTECH.COM


Join Date: Oct 2011
Posts: 9,393
Thanks: 98
Thanked 106 Times in 84 Posts
Mentioned: 3 Post(s)
Quoted: 16 Post(s)
Feedback Score: 10 reviews
Sounds like either your FICM harness(es) might be either loose or the logic side of the FICM took a dump on you. Try playing with the harnesses and if that doesn't work than swap the FICM with a known good complete FICM and see if it buzzes and starts.

l BRYAN l


To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.


To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
COMPIGNTECH .COM

Look us up on Facebook
COMPRESSION IGNITION TECHNOLOGIES

l 2005 l Ford F250 l FTX l
[A Few Odds-N-Ends]


To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
Tuscany is offline
post #4 of 11 Old 01-13-2013, 01:38 PM Thread Starter
Compression Ignition Addict

2003kingranch's Avatar

Join Date: Dec 2010
Location: IOWA
Posts: 2,542
Thanks: 0
Thanked 0 Times in 0 Posts
Mentioned: 0 Post(s)
Quoted: 0 Post(s)
Feedback Score: 0 reviews
Send a message via Skype™ to 2003kingranch
Swapped another ficm into it. Fired right up.


Sent from my iPhone using AutoGuide.com Free App


To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
[/URL]

[CENTER]2012 King Ranch
22k deleted at 1k
5" FLO-PRO
S&B Intake
Sinister Egr Delete
MiniMax/ SPE Tunes
466/953 on 37's
6" 4 link
37's on 22's
Bags and compressor
RBP mudflaps
transfer tank tool box.
9" 2" poly boss v blade
Should have kept my 6.0.....
2003kingranch is offline
post #5 of 11 Old 01-13-2013, 01:44 PM
WWW.COMPIGNTECH.COM


Join Date: Oct 2011
Posts: 9,393
Thanks: 98
Thanked 106 Times in 84 Posts
Mentioned: 3 Post(s)
Quoted: 16 Post(s)
Feedback Score: 10 reviews
Well there you go.

l BRYAN l


To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.


To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
COMPIGNTECH .COM

Look us up on Facebook
COMPRESSION IGNITION TECHNOLOGIES

l 2005 l Ford F250 l FTX l
[A Few Odds-N-Ends]


To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
Tuscany is offline
post #6 of 11 Old 01-13-2013, 07:45 PM Thread Starter
Compression Ignition Addict

2003kingranch's Avatar

Join Date: Dec 2010
Location: IOWA
Posts: 2,542
Thanks: 0
Thanked 0 Times in 0 Posts
Mentioned: 0 Post(s)
Quoted: 0 Post(s)
Feedback Score: 0 reviews
Send a message via Skype™ to 2003kingranch
its strange. that it would go out right after doing an egr delete. it ran horrible when it was dropped off. but ficm checked out good. pulled the ficm apart and soldered it. got it to start but ran horrible. oh well. new one should be in tomorrow


To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
[/URL]

[CENTER]2012 King Ranch
22k deleted at 1k
5" FLO-PRO
S&B Intake
Sinister Egr Delete
MiniMax/ SPE Tunes
466/953 on 37's
6" 4 link
37's on 22's
Bags and compressor
RBP mudflaps
transfer tank tool box.
9" 2" poly boss v blade
Should have kept my 6.0.....
2003kingranch is offline
post #7 of 11 Old 01-13-2013, 08:38 PM Thread Starter
Compression Ignition Addict

2003kingranch's Avatar

Join Date: Dec 2010
Location: IOWA
Posts: 2,542
Thanks: 0
Thanked 0 Times in 0 Posts
Mentioned: 0 Post(s)
Quoted: 0 Post(s)
Feedback Score: 0 reviews
Send a message via Skype™ to 2003kingranch
Oh and after I soldered it my modis was saying ficm output v was like 132v lol


Sent from my iPhone using AutoGuide.com Free App


To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
[/URL]

[CENTER]2012 King Ranch
22k deleted at 1k
5" FLO-PRO
S&B Intake
Sinister Egr Delete
MiniMax/ SPE Tunes
466/953 on 37's
6" 4 link
37's on 22's
Bags and compressor
RBP mudflaps
transfer tank tool box.
9" 2" poly boss v blade
Should have kept my 6.0.....
2003kingranch is offline
post #8 of 11 Old 01-13-2013, 08:48 PM
WWW.COMPIGNTECH.COM


Join Date: Oct 2011
Posts: 9,393
Thanks: 98
Thanked 106 Times in 84 Posts
Mentioned: 3 Post(s)
Quoted: 16 Post(s)
Feedback Score: 10 reviews
Yeah that's no bueno. Lol.

l BRYAN l


To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.


To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
COMPIGNTECH .COM

Look us up on Facebook
COMPRESSION IGNITION TECHNOLOGIES

l 2005 l Ford F250 l FTX l
[A Few Odds-N-Ends]


To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
Tuscany is offline
post #9 of 11 Old 01-15-2013, 07:19 AM Thread Starter
Compression Ignition Addict

2003kingranch's Avatar

Join Date: Dec 2010
Location: IOWA
Posts: 2,542
Thanks: 0
Thanked 0 Times in 0 Posts
Mentioned: 0 Post(s)
Quoted: 0 Post(s)
Feedback Score: 0 reviews
Send a message via Skype™ to 2003kingranch
Advanced auto gave me half the board. It fired right up twice after installation. Now no injector buzz again and no start


Sent from my iPhone using AutoGuide.com Free App


To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
[/URL]

[CENTER]2012 King Ranch
22k deleted at 1k
5" FLO-PRO
S&B Intake
Sinister Egr Delete
MiniMax/ SPE Tunes
466/953 on 37's
6" 4 link
37's on 22's
Bags and compressor
RBP mudflaps
transfer tank tool box.
9" 2" poly boss v blade
Should have kept my 6.0.....
2003kingranch is offline
post #10 of 11 Old 01-15-2013, 10:18 AM
WWW.COMPIGNTECH.COM


Join Date: Oct 2011
Posts: 9,393
Thanks: 98
Thanked 106 Times in 84 Posts
Mentioned: 3 Post(s)
Quoted: 16 Post(s)
Feedback Score: 10 reviews
Take it back and buy a full ficm from your local international dealer.
