Gas to diesel swap

Im in the market for a powerstroke excursion. The problem that I find is that I want one thats a manual. If memory serves correctly, Ford never made a manual excursion.

I found this guy on CL close to me. Its the V10. I was curious on how difficult it would be to convert to a diesel.

2000 Ford Excursion

I dont really mind the work. I understand that I will need a doner truck.
Can I get a doner from an F250 or F350? If so, crew cab, 6.5' bed?

My main question is if its worth it to do. Like I said, I want a manual, I want the 7.3 diesel, and I want the 4x4 in an excursion.

Thanks for the help guys.

Justin

Please sign this petition to have the commercial vehicle fees removed from your yearly registration (CA residents only)

http://www.petitiononline.com/windy520/petition.html



http://www.youtube.com/watch?v=k9k4MDATV6Y
http://www.youtube.com/watch?v=abNvRSUIf_8
jwindbigler is offline
post #2 of 15 Old 09-11-2013, 02:26 AM
Compression Ignition Addict


RollinEarly99's Avatar

Join Date: May 2008
Location: Klamath Falls
Posts: 3,383
Thanks: 30
Thanked 25 Times in 24 Posts
Mentioned: 0 Post(s)
Quoted: 8 Post(s)
Feedback Score: 10 reviews
Nothing is impossible, but it is a lot of work. You would be better off getting a diesel excursion and converting the automatic into a manual. A lot less work and a lot less money. Or you could get a great running diesel pickup and swap an excursion body on the diesel pickup frame. Only thing that's different is the fuel tank.

05 F-250 Crew Cab Short Bed
ARPs w/OEM Gaskets
MTW Stage 2 w/batmowheel
BPD oil cooler w/ cold weather package
BPD Updated umm...Everything
BPD bypass oil filter
BPD FICM 58v
Spring Mod
Egr deleted
4" Duals
Edge CTS
Custom grille made by Me
X3 w/Matts SRL+/SRLxx and Tow Tunes
Tony WildmanExtreme w/early lockup



RollinEarly99 is offline
post #3 of 15 Old 09-11-2013, 06:32 AM
Compression Ignition Addict

Join Date: Jun 2012
Posts: 380
Thanks: 0
Thanked 8 Times in 8 Posts
Mentioned: 0 Post(s)
Quoted: 15 Post(s)
Feedback Score: 0 reviews
Quote:
Originally Posted by RollinEarly99 View Post
Nothing is impossible, but it is a lot of work. You would be better off getting a diesel excursion and converting the automatic into a manual. A lot less work and a lot less money. Or you could get a great running diesel pickup and swap an excursion body on the diesel pickup frame. Only thing that's different is the fuel tank.
I heard the frame is slightly different. The Ex is sorta a strait frame vs the superduty has the rise in the frame. I don't know this for a fact though.

He is right it would be more cost effective if you bought an Excursion that was a diesel & changed the tranny out.

2000 Ford Excursion Limited 4x4 Diesel
2007 Jeep Wrangler unlimited on 1 tons & with 41.5" Pitbull Rockers
TBJK is offline
post #4 of 15 Old 09-11-2013, 07:57 AM
Compression Ignition Addict


RollinEarly99's Avatar

Join Date: May 2008
Location: Klamath Falls
Posts: 3,383
Thanks: 30
Thanked 25 Times in 24 Posts
Mentioned: 0 Post(s)
Quoted: 8 Post(s)
Feedback Score: 10 reviews
Same frame.... f-series and Super dutys are the same, f-150 and expedition, finally ranger and explorer. Of course now its all changed but back in 2005 and previous the motors, trans, drivetrain and frames were all the same.

05 F-250 Crew Cab Short Bed
ARPs w/OEM Gaskets
MTW Stage 2 w/batmowheel
BPD oil cooler w/ cold weather package
BPD Updated umm...Everything
BPD bypass oil filter
BPD FICM 58v
Spring Mod
Egr deleted
4" Duals
Edge CTS
Custom grille made by Me
X3 w/Matts SRL+/SRLxx and Tow Tunes
Tony WildmanExtreme w/early lockup



RollinEarly99 is offline
post #5 of 15 Old 09-11-2013, 08:02 AM
Compression Ignition Addict

Raul@Stealth Automotive's Avatar

Join Date: Oct 2006
Location: Ventura County, CA
Posts: 20,359
Thanks: 23
Thanked 30 Times in 17 Posts
Mentioned: 0 Post(s)
Quoted: 0 Post(s)
Feedback Score: 2 reviews
Send a message via AIM to Raul@Stealth Automotive
Raul@Stealth Automotive is offline
post #6 of 15 Old 09-11-2013, 08:57 AM
Compression Ignition Addict

Join Date: Jun 2012
Posts: 380
Thanks: 0
Thanked 8 Times in 8 Posts
Mentioned: 0 Post(s)
Quoted: 15 Post(s)
Feedback Score: 0 reviews
I found some drawings that show otherwise. If you have the ablility to weld it wouldn't be a problem. If you look at the frame for the same wheelbase (single cab truck) the frame on he truck takes a bend up vs the excursion the frame does not take that same bend until behind the rear doors. The drawings I found on Ford truck forum
https://www.fleet.ford.com/truckbbas...l/2002/164.pdf
https://www.fleet.ford.com/truckbbas...l/2002/108.pdf

2000 Ford Excursion Limited 4x4 Diesel
2007 Jeep Wrangler unlimited on 1 tons & with 41.5" Pitbull Rockers
TBJK is offline
post #7 of 15 Old 09-11-2013, 01:37 PM
Serving Our Country!

alaskan155's Avatar

Join Date: Mar 2013
Posts: 1,107
Thanks: 9
Thanked 44 Times in 43 Posts
Mentioned: 0 Post(s)
Quoted: 50 Post(s)
Feedback Score: 1 reviews
Quote:
Originally Posted by RollinEarly99 View Post
Same frame.... f-series and Super dutys are the same, f-150 and expedition, finally ranger and explorer. Of course now its all changed but back in 2005 and previous the motors, trans, drivetrain and frames were all the same.
rightttttttttt


about the only thing a ranger and explorer frame share is from trans cross-member forward , from the trans cross member back they are totally different

f-series and superduty, about the only common is the inner bed and tailgate, the 97-04 f150 frame is 2-pieces and ifs in the front, the super-duty is sfa in the front, even the obs frames are different. 05+ are hydro-formed, the super-duty is c-channel

f150 vs expidition
same as ranger and explorer changes at the trans cross member back, early expeditions ones had coils vs leafs and irs on the later ones,


my bet is the excursion frame has less kick up than the superduty to compensate for body mounts, the bed on any truck is hard mounted

either way the frames are different from the trans cross member back,

be easier to drop the diesel in the gas excursion and get the fuel rails and diesel tank for the excursion, or convert a auto to manual excursion

a body swap sounds like a headache

2002 F250 7.3/JW Tow master 4r100 205k miles
Mods:explorer heater valve, WR GP relay, RiffRAff boots, lariat overhead console, Hydra chip, 6637 mod, 6.0 cooler, AIH delete and isspro2 trans, egt, and boost gauges. 92 gallon aux tank with a total capacity of 130gallons, 1800 mile range , 4" MBRP straight Piped. 2" Warrior shackles
alaskan155 is offline
post #8 of 15 Old 09-11-2013, 03:27 PM
Compression Ignition Addict


RollinEarly99's Avatar

Join Date: May 2008
Location: Klamath Falls
Posts: 3,383
Thanks: 30
Thanked 25 Times in 24 Posts
Mentioned: 0 Post(s)
Quoted: 8 Post(s)
Feedback Score: 10 reviews
Quote:
Originally Posted by RollinEarly99 View Post
Same frame.... 99+ f-250 f-350 and Excursions are the same, f-150 and expedition, finally ranger and explorer. Of course now its all changed but back in 2005 and previous the motors, trans, drivetrain and frames were all the same.
Edited quote...

I meant 99+ f-250 f-350 and excursions are the same. When I helped a friend replace his rear end two years ago in his 03 excursion we went to a junk yard and used an 04 f-250 rear end... Bolted right up. I am aware of some expeditions having IRS and air bags... But was always told the frames and "plain Jane" versions of the expeditions were exactly the same as the f-150... Up to a certain year.

Obviously f-series and Superdutys are different when comparing 98 and older vs 99 and newer (excluding f-150's)... That was a typo, my bad.

Different years play a role, but same year ranger explorers are the same.... Right? Same goes for expeditions and f-150

05 F-250 Crew Cab Short Bed
ARPs w/OEM Gaskets
MTW Stage 2 w/batmowheel
BPD oil cooler w/ cold weather package
BPD Updated umm...Everything
BPD bypass oil filter
BPD FICM 58v
Spring Mod
Egr deleted
4" Duals
Edge CTS
Custom grille made by Me
X3 w/Matts SRL+/SRLxx and Tow Tunes
Tony WildmanExtreme w/early lockup



RollinEarly99 is offline
post #9 of 15 Old 09-11-2013, 03:37 PM
Compression Ignition Addict


RollinEarly99's Avatar

Join Date: May 2008
Location: Klamath Falls
Posts: 3,383
Thanks: 30
Thanked 25 Times in 24 Posts
Mentioned: 0 Post(s)
Quoted: 8 Post(s)
Feedback Score: 10 reviews
Quote:
Originally Posted by alaskan155 View Post
rightttttttttt
Found this info on another site:

Basically, Ford used a different rear frame that has many similarities to the truck frame. The major changes were in the rear crossbraces, which had to be different to accomodate the large rear fuel tank, along with differences based on having a full body and not a body/separate bed design. The pickup frame needs a stronger twist rating than the full body SUV frame since the SUV body adds stiffness. The frame also is not as flat(straight ) as a pickup frame, and has a hump for the rear axle, and then drops some at a light angle to acommodate the rear hitch.

The frame and body is apparently able to handle load abilities just a little beyond the frame of a standard F250 of the same years.

However, the Excursion carries 1400lbs more weight behind the driver than the standard F250 due to the full enclosure, added interior, hatch, windows, and more fuel.


So, it appears Ford designed a frame based on slightly higher specs than the 250. When you subtract the extra 1400 lbs that the Excursion carries from the load rating of the F250, you get unsuprisingly, a little bit lower than the rated load rating of the Excursion.



I stand corrected... Obviously you can not drop an Excusrions body one a super duty frame.
I assumed from my previous experiences (replacing certain parts) that the two where identical.

05 F-250 Crew Cab Short Bed
ARPs w/OEM Gaskets
MTW Stage 2 w/batmowheel
BPD oil cooler w/ cold weather package
BPD Updated umm...Everything
BPD bypass oil filter
BPD FICM 58v
Spring Mod
Egr deleted
4" Duals
Edge CTS
Custom grille made by Me
X3 w/Matts SRL+/SRLxx and Tow Tunes
Tony WildmanExtreme w/early lockup



RollinEarly99 is offline
post #10 of 15 Old 09-11-2013, 04:17 PM
Compression Ignition Addict


RollinEarly99's Avatar

Join Date: May 2008
Location: Klamath Falls
Posts: 3,383
Thanks: 30
Thanked 25 Times in 24 Posts
Mentioned: 0 Post(s)
Quoted: 8 Post(s)
Feedback Score: 10 reviews
I never mind when I'm proved wrong. I actually prefer it so the information that's given by me or others is accurate.

So basically the OP needs to actually get an Excursion and swap a ZF-6 into it if he wants a manual trans Excursion.

05 F-250 Crew Cab Short Bed
ARPs w/OEM Gaskets
MTW Stage 2 w/batmowheel
BPD oil cooler w/ cold weather package
BPD Updated umm...Everything
BPD bypass oil filter
BPD FICM 58v
Spring Mod
Egr deleted
4" Duals
Edge CTS
Custom grille made by Me
X3 w/Matts SRL+/SRLxx and Tow Tunes
Tony WildmanExtreme w/early lockup



RollinEarly99 is offline
