GPR not activating

2001 f350 7.3 with 350,000 miles. Vehicle in California. Recently noticed hard to start first thing in the morning. I have read through the forums and completed some testing. Glow plugs all test at 0.9 ohms. GPR does not activate when key is in the on position. I have tested the GPR by grounding it to the frame, turning key to on position and I can hear the relay activate and I also get a voltage reading on the second large post. Any suggestions on what to test next or how to remedy the problem. Thanks

Arrrgh! is offline
Sponsored Links
Advertisement

post #2 of 5 Old 12-29-2013, 03:56 PM
Super Moderator



SuperCrutyPS's Avatar

Join Date: Jul 2008
Location: Orangevale, CA
Posts: 15,558
Thanks: 88
Thanked 517 Times in 501 Posts
Mentioned: 5 Post(s)
Quoted: 288 Post(s)
Garage
Feedback Score: 0 reviews
Do you have one of these?



-OR-



I ask because I own a CA truck and it has the module, not the relay. But there is a relay next to the module.


Where in CA do you live?


To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.

To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.

Owner | Operator: Darryl
My Truck Garage:
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.

Tow Toy Garage :
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.

United States Navy - IC2 - '76-'80
SuperCrutyPS is online now
post #3 of 5 Old 12-29-2013, 04:03 PM Thread Starter
Powerstroke.org Rookie

Join Date: Dec 2013
Posts: 9
Thanks: 0
Thanked 0 Times in 0 Posts
Mentioned: 0 Post(s)
Quoted: 0 Post(s)
Feedback Score: 0 reviews
Actually I have both of those. Is there a way to test the controller? I live in Oceanside. Thanks for the quick response
Arrrgh! is offline
post #4 of 5 Old 01-04-2014, 03:41 PM Thread Starter
Powerstroke.org Rookie

Join Date: Dec 2013
Posts: 9
Thanks: 0
Thanked 0 Times in 0 Posts
Mentioned: 0 Post(s)
Quoted: 0 Post(s)
Feedback Score: 0 reviews
Quote:
Originally Posted by Arrrgh! View Post
Actually I have both of those. Is there a way to test the controller? I live in Oceanside. Thanks for the quick response
So am update. I have tested the GPR and it is good. I just installed a new GPR controller from Rockauto. All i get when i turn the key is "click." Where do i go from here?? Thanks
Arrrgh! is offline
post #5 of 5 Old 01-06-2014, 07:00 PM
Powerstroke.org Fanatic

Join Date: Feb 2008
Location: Wilmington, NC
Posts: 97
Thanks: 0
Thanked 3 Times in 2 Posts
Mentioned: 0 Post(s)
Quoted: 0 Post(s)
Feedback Score: 0 reviews
when my oil temp senses above some temp (not sure exactly what temp), my gpr doesn't even come on. Is it possible that the sensor telling the circuitry when to come on and when to stay off is failed? If the logic is telling the GPR that it is not needed to start the engine, maybe that sensor needs replaced. Just an idea?


To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.

2000 F350 Crew Cab 7.3 liter 4x4 short bed, 6 pos w/PHP, 6637 filter, hutch, harpoon, 4" downpipe, 5" exhaust, ISSPRO gages, 305 series tires, stock suspension with level kit up front, '05 headlight mod.
2001 F250 ECSB 4x4 - sold
2001 F250 CCSB 2WD -sold
2002 F250 ECSB 4x4 lifted -sold
Mama's 2009 Expedition EL 4x4
biscayne is offline
