console install help

Went from a jump seat to a center console set up. I went to ford and got the inserts for the floor board . I put them in the floor board but just pull out. My question is how do you get them to stay in so you can mount the console. Do I need to like jb weld them in or something? Truck is a 02 f250 crew cab using a 06 console.

This is what I got from the dealer for mounting.


Attachment 179249

Attachment 179257

Attachment 179265

Last edited by hellraiserford; 02-04-2014 at 03:39 PM.
hellraiserford is offline
post #2 of 8 Old 10-09-2013, 08:30 PM Thread Starter
Compression Ignition Addict

hellraiserford's Avatar

Join Date: Mar 2010
Location: baton rouge
Posts: 273
Thanks: 0
Thanked 1 Time in 1 Post
Mentioned: 2 Post(s)
Quoted: 0 Post(s)
Feedback Score: 7 reviews
Send a message via Yahoo to hellraiserford
Anyone know ?
hellraiserford is offline
post #3 of 8 Old 10-10-2013, 11:56 AM
Chapter Director


Rammstein1224's Avatar

Join Date: Aug 2012
Location: Davenport, IA
Posts: 2,931
Thanks: 4
Thanked 45 Times in 37 Posts
Mentioned: 0 Post(s)
Quoted: 0 Post(s)
Feedback Score: 5 reviews
They need to be pressed in. Im not sure if they can be hammered in or if that will damage them. Your truck didnt come with the nuts already installed?

Local Jackass member Pat

Battle cry of every 6.0 owner out there
Quote:
Originally Posted by access_max View Post
With the issues fixed a 6.0 can run circles around a 7.3.
2000 F-350 7.3L ZF6
Standard 7.3 mods
SCT tuned
8" Fabtech lift 13" total
5:13 Gears
46" Goodyear MVTs Military takeoffs
Bushwacker Cut-Out Fender Flares
Ranch Hand front and rear bumper
On-board air W/Semi horns

1995 F-350 7.3L E4OD DRW
Standard 7.3 mods
PHP Hydra W/Tony Wildman tunes
160/0 Injectors
T-500 HPOP
E-fuel Conversion
West Coast mirrors
Rammstein1224 is offline
post #4 of 8 Old 10-10-2013, 01:23 PM Thread Starter
Compression Ignition Addict

hellraiserford's Avatar

Join Date: Mar 2010
Location: baton rouge
Posts: 273
Thanks: 0
Thanked 1 Time in 1 Post
Mentioned: 2 Post(s)
Quoted: 0 Post(s)
Feedback Score: 7 reviews
Send a message via Yahoo to hellraiserford
No it didn't come with the nuts already pressed in. The package of nuts I got from the dealer slide into the holes in the floor board all the way. Just have no idea on how to keep them from coming out.
hellraiserford is offline
post #5 of 8 Old 10-10-2013, 01:25 PM
Chapter Director


Rammstein1224's Avatar

Join Date: Aug 2012
Location: Davenport, IA
Posts: 2,931
Thanks: 4
Thanked 45 Times in 37 Posts
Mentioned: 0 Post(s)
Quoted: 0 Post(s)
Feedback Score: 5 reviews
Quote:
Originally Posted by hellraiserford View Post
No it didn't come with the nuts already pressed in. The package of nuts I got from the dealer slide into the holes in the floor board all the way. Just have no idea on how to keep them from coming out.
Are there "teeth" persay below the flange?

Local Jackass member Pat

Battle cry of every 6.0 owner out there
Quote:
Originally Posted by access_max View Post
With the issues fixed a 6.0 can run circles around a 7.3.
2000 F-350 7.3L ZF6
Standard 7.3 mods
SCT tuned
8" Fabtech lift 13" total
5:13 Gears
46" Goodyear MVTs Military takeoffs
Bushwacker Cut-Out Fender Flares
Ranch Hand front and rear bumper
On-board air W/Semi horns

1995 F-350 7.3L E4OD DRW
Standard 7.3 mods
PHP Hydra W/Tony Wildman tunes
160/0 Injectors
T-500 HPOP
E-fuel Conversion
West Coast mirrors
Rammstein1224 is offline
post #6 of 8 Old 10-10-2013, 01:32 PM Thread Starter
Compression Ignition Addict

hellraiserford's Avatar

Join Date: Mar 2010
Location: baton rouge
Posts: 273
Thanks: 0
Thanked 1 Time in 1 Post
Mentioned: 2 Post(s)
Quoted: 0 Post(s)
Feedback Score: 7 reviews
Send a message via Yahoo to hellraiserford
The factory holes in the floor board are cut in the shape of a nut. The hole is not round. Neither the insert or the floor board have any teeth to grab it and lock it into the floor board. I don't know if the dealer gave me the wrong insert or what the deal is. The parts guy didn't seem to know too much about fords or parts. I looked the part number up on line and some things say super duty but most of the listings I saw for this part number were for like a luggage rack for an expedition. So idk. Was hoping someone knew the right factory part number for the insert or something else I can use to mount it. Tried going under the truck to just see if I could use nuts but on the rear 2 there inside the body channel and unable to get to the bolt.
hellraiserford is offline
post #7 of 8 Old 10-10-2013, 02:48 PM
Chapter Director


Rammstein1224's Avatar

Join Date: Aug 2012
Location: Davenport, IA
Posts: 2,931
Thanks: 4
Thanked 45 Times in 37 Posts
Mentioned: 0 Post(s)
Quoted: 0 Post(s)
Feedback Score: 5 reviews
Quote:
Originally Posted by hellraiserford View Post
The factory holes in the floor board are cut in the shape of a nut. The hole is not round. Neither the insert or the floor board have any teeth to grab it and lock it into the floor board. I don't know if the dealer gave me the wrong insert or what the deal is. The parts guy didn't seem to know too much about fords or parts. I looked the part number up on line and some things say super duty but most of the listings I saw for this part number were for like a luggage rack for an expedition. So idk. Was hoping someone knew the right factory part number for the insert or something else I can use to mount it. Tried going under the truck to just see if I could use nuts but on the rear 2 there inside the body channel and unable to get to the bolt.
Heres what mine looks like from the bottom

Local Jackass member Pat

Battle cry of every 6.0 owner out there
Quote:
Originally Posted by access_max View Post
With the issues fixed a 6.0 can run circles around a 7.3.
2000 F-350 7.3L ZF6
Standard 7.3 mods
SCT tuned
8" Fabtech lift 13" total
5:13 Gears
46" Goodyear MVTs Military takeoffs
Bushwacker Cut-Out Fender Flares
Ranch Hand front and rear bumper
On-board air W/Semi horns

1995 F-350 7.3L E4OD DRW
Standard 7.3 mods
PHP Hydra W/Tony Wildman tunes
160/0 Injectors
T-500 HPOP
E-fuel Conversion
West Coast mirrors

Last edited by Rammstein1224; 05-06-2014 at 09:52 AM.
Rammstein1224 is offline
post #8 of 8 Old 10-11-2013, 07:18 AM
Compression Ignition Addict

Join Date: Jun 2012
Posts: 378
Thanks: 0
Thanked 8 Times in 8 Posts
Mentioned: 0 Post(s)
Quoted: 15 Post(s)
Feedback Score: 0 reviews
That looks like a rivet nut. They have to be basically tightened up in spot. It usually requires a large rivet nut set tool but can be expanded with a nut & bolt in the right size drilled hole. I have used a power steering pump installer & also when I was building jeep parts hat required rivet nuts I made 2 pieces of plate, one had one hole in the center for the bolt to rivet nut then the other had 3 holes,2 of which were tapped so all I had to do was tighten the 2 bolts to expand it.

2000 Ford Excursion Limited 4x4 Diesel
2007 Jeep Wrangler unlimited on 1 tons & with 41.5" Pitbull Rockers
TBJK is offline
