Tie rod ends

where can i find a set of tie rod ends? what brand is best

Vegistrokin
2000 XC 4x4

-CORY
Orlando, FL
Cory S is offline
post #2 of 8 Old 05-06-2010, 12:56 PM Thread Starter
Compression Ignition Addict

Cory S's Avatar

Join Date: Aug 2008
Posts: 2,464
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks: 0
Thanked 1 Time in 1 Post
Feedback Score: 0 reviews
Send a message via AIM to Cory S
and any pointers on changing them? is it hard?

Vegistrokin
2000 XC 4x4

-CORY
Orlando, FL
Cory S is offline
post #3 of 8 Old 05-06-2010, 02:53 PM
Compression Ignition Addict

Join Date: Sep 2007
Location: Edmonton Alberta Canada
Posts: 363
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks: 0
Thanked 0 Times in 0 Posts
Feedback Score: 0 reviews
Its almost time for me to do some front end work also, an i have been wondering the same thing...

Are NAPA parts good as long as they come with Grease Nipples?

Im sure someone will chime in an let us know what the goods an bads are...

-Henry


-2002 F350 Lariat
C/C S/B 4x4
-Stage 2 AFE
-Straight Piped
-TS 6 Position Chip
S/75/100/140/HI/AT
-Edge Evolution II
as Gauge Pod
-33/12.5/16
Pro Comp A/T's
-Ultra Rims
-Halo Projector
-Tru Cool Trans Cooler
F350Buster is offline
post #4 of 8 Old 05-06-2010, 05:21 PM
Compression Ignition Addict

Zaairman's Avatar

Join Date: Apr 2007
Location: Wright City, MO
Posts: 3,030
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 12 Post(s)
Thanks: 7
Thanked 18 Times in 18 Posts
Feedback Score: 1 reviews
Can't go wrong with Moogs in my book...

Zach
2000/2006ish Ford F-250 Larryette 7.3 Powerstroke 4x4
5" Sewer Pipe Exhaust (video clip), DIY 6637 Intake, Wicked Wheel'd, De-foiled, Missing EBPV, Edge Juice with Attitude, Few leaves added here and there, 35" BFGs, 16x10 Eagle Alloys, Alpine W200

SLAPS Member #153
Zaairman is offline
post #5 of 8 Old 05-07-2010, 06:24 AM
Member

Join Date: Jun 2009
Posts: 41
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks: 0
Thanked 0 Times in 0 Posts
Feedback Score: 0 reviews
I did as much moog as I could when I took my front end apart at 99K

Upper joints $39 each
Lower joints $50 each
Cross steering setup, 119 pass side, 20 adjuster, 29 driver
Pitman to pass, pitman end 39, adjust 20, pass end 39

Axle seals 52 each, tube seals 14 each
Axle bearings were good, but I was ready at 145 each with the anti-lock
Rotors 49 each
pads 45
Slide pins and hardware for both sides 27 (ALWAYS replace the F'in slider pins $7 a side insurance, mix disc brake grease and antiseize and PLASTER the hell out of them when you install them)

I also eliminated the vacum hubs and went to the manual Mile Markers (Its a dually and superwinch said theirs wouldn't work. I also didn't need the MM conversion nut kit, maybe single wheels do, but my dually didn't need that, $60 down the drain)

While I was in there and had the entire thing apart I also did Rancho shocks and a 2" leveling kit, 45 each for the 5000 shocks and 279 for the full leaf leveling kit with drop pivot bracket.

I didn't add it up but I figure a ball joint job would be around 350-400 for all the joints and seals and misc. Tie rod job about 300. Brake job about 175. Leveling about 500. Hubs about 170. Entire new front end with doing the sway bar bushings, u-joints, and hub bearings (which I didn't do those 3), about 1300. I have about the same in with my leveling kit and shocks.
nydiver is offline
post #6 of 8 Old 05-07-2010, 06:33 AM
Serving Our Country!

cpayne6335's Avatar

Join Date: Oct 2009
Location: Germantown, Ohio
Posts: 441
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks: 0
Thanked 0 Times in 0 Posts
Feedback Score: 0 reviews
I have used moog. Tried the TRW, and they failed very quickly.

One thing I have done is look at the part numbers. If the store brand number is the same as the moog one, it just is the same part, differnt box. I think Pepboys uses moog, and Orilley's uses moog. Just make sure the part numbers match up. That or even ask them. That is how I saved some coin doing the work.

The job is not that hard, just get a ball joint remover, or pickle fork. If all else fails, heat it up.

I did my tie rods, hubs, seals, warn lockouts, and both upper and lower ball joints in one day, but I had the ball joint tool, pickle fork, torch and air tools.

Looking for a FORD.
Chris
US Army, MOS:88M Ft. Lewis 17th Fires
cpayne6335 is offline
post #7 of 8 Old 05-07-2010, 07:49 AM
Member

Join Date: Jun 2009
Posts: 41
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks: 0
Thanked 0 Times in 0 Posts
Feedback Score: 0 reviews
I forgot to mention that, chances are pretty good you'll need a torch, at the very least a 5lb mini sledge to beat things out. I needed the torch to get the dually hub extenders off. Next fun was getting the hub bearings out, take the tie rod off, turn it all the way to one direction and carefully drive the hub out with a punch and hammer. The caliper slide pins were FROZEN solid and required the torch to get those out and to burn the rust inside once they were out. Frankly if your pins are frozen you MUST have a torch, that or alot of patience, I prefer the torch method, run a drill in there to just clean it up, then pour it full of alchol and light it up and burn anything left in the bores out, clean the bores throughly with brake cleaner, then slather disc brake grease and anti-seize in the bores and on the pins so hopefully that never happens again.

Another trick I figured out is the upper joint just keeps spinning when you go to tighten the nut (or is it the lower?) anyways once the hub is put back onto the axle end put a jack under the lower joint and jack up slightly on the spindle or hub, the ball joints go tight and that joint no longer spins and you can fully tighten the nut.
nydiver is offline
post #8 of 8 Old 05-07-2010, 08:24 AM
DJM
Compression Ignition Addict

DJM's Avatar

Join Date: Sep 2005
Location: Springfield ,OR
Posts: 796
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks: 0
Thanked 0 Times in 0 Posts
Feedback Score: 0 reviews
Moog is good but believe it or not the factory Ford ones will probably be the best in my opinion. Not sure who Ford has make them.

2001 Crew Cab, Auto
6in lift, 37Toyo's
DP F6 60eco,80tow,80eco,120
Wicked Wheel
Foil Delete
Isspro EV2 Guages
HPX Line
RiffRaff FRx
4" Exhaust
AFE Big Boost
FS 2500 Filter


DJM is offline
