OIL LEAK HELP

So it thought I blew my hpop o rings out again because I found oil towards the front of the valley. But after checking the fittings they appeared to be bone dry, so now I am lost as to what the problem could be. The oil mostly drips on the starter side of the engine down the oil pan. I need some help from you guys who have had similar problems. Anything would be great, thanks.
Reply With Quote Quick reply to this message
Sponsored Links
Advertisement

  #2
Old 04-06-2010, 08:53 AM
Compression Ignition Addict

Join Date: May 2008
Posts: 1,082
Thanks: 0
Thanked 0 Times in 0 Posts
Feedback Score: 0 reviews
Send a message via AIM to Nally7.3Powerstroke
BUMP..............
Reply With Quote Quick reply to this message
  #3
Old 04-06-2010, 09:06 AM
Compression Ignition Addict


Join Date: Nov 2008
Location: Crane/Evansville, IN
Posts: 7,847
Thanks: 0
Thanked 1 Time in 1 Post
Feedback Score: 1 reviews
You sure that wasnt old oil up front? I cant help a whole lot cuase im chasing a similar oil leak myself.
Reply With Quote Quick reply to this message
  #4
Old 04-06-2010, 06:42 PM
Banned


Join Date: Oct 2009
Location: Riverside/Norco, Ca
Posts: 3,771
Thanks: 0
Thanked 0 Times in 0 Posts
Feedback Score: 2 reviews
weird... i mean my whole valley was full of oil even from the turbo pedestal oring. my ebpv rod leaks now. pos... check all that stuff out.
Reply With Quote Quick reply to this message
  #5
Old 04-08-2010, 07:17 PM
Compression Ignition Addict

Join Date: May 2008
Posts: 1,082
Thanks: 0
Thanked 0 Times in 0 Posts
Feedback Score: 0 reviews
Send a message via AIM to Nally7.3Powerstroke
So, I decided im going to have to pull the turbo off to check for all posibilities back there. Looks like this saturday Im going to have a little project going on. Hopefully I can get it apart relatively easy with no problems, knock on wood, lol. Will feed you guys in with anything I find and if anyone has some tips as to what to look for it would be greatly appreciated!!
Reply With Quote Quick reply to this message
  #6
Old 04-15-2010, 03:37 PM
Compression Ignition Addict

Join Date: May 2008
Posts: 1,082
Thanks: 0
Thanked 0 Times in 0 Posts
Feedback Score: 0 reviews
Send a message via AIM to Nally7.3Powerstroke
Well I never got to pull the turbo because it rained over the weekend I was going to do it... so I got out of school early tonight and came home and decided to check the truck out. I cleaned the valley so it was spotless of oil so I could see if the oil up there was old or not, and come to find out tonight a puddle has formed again right behind the HPOP. Are there any cases where the pump itself leaks rather then the pressure lines? Because to me the pressure lines and end plug look dry with no residue. I am just starting to get confused at this point as to what the problem could be.
Reply With Quote Quick reply to this message
  #7
Old 04-16-2010, 05:55 AM
Member


Join Date: Dec 2007
Location: Morrison colorado
Posts: 63
Thanks: 0
Thanked 0 Times in 0 Posts
Feedback Score: 0 reviews
if its by the hpop then its an oring. Get a flashlight and a mirror and check the plug that faces the cab of the motor and the plug underneath the so called non servicable plug. With the truck running you should be able to see oil leaking out somewhere from one of those places. Mine was from the plug itself.

\Here is a pdf i found for ya.
http://www.thedieselstop.com/faq/949...les/040404.pdf
Reply With Quote Quick reply to this message
  #8
Old 04-16-2010, 07:57 AM
Compression Ignition Addict

Join Date: May 2008
Posts: 1,082
Thanks: 0
Thanked 0 Times in 0 Posts
Feedback Score: 0 reviews
Send a message via AIM to Nally7.3Powerstroke
I checked the end plug and both pressure lines and there is no oil coming out anywhere around them...
Reply With Quote Quick reply to this message
  #9
Old 04-16-2010, 08:14 AM
Compression Ignition Addict


Join Date: Dec 2009
Location: Montgomery, TX
Posts: 539
Thanks: 0
Thanked 0 Times in 0 Posts
Feedback Score: 0 reviews
There is also a gasket where the HPOP mates to the block. Maybe you should get the complete gasket set from dieselorings.com and just replace everything while you've got it off.
Reply With Quote Quick reply to this message
  #10
Old 04-16-2010, 08:22 AM
Compression Ignition Addict

Join Date: May 2008
Posts: 1,082
Thanks: 0
Thanked 0 Times in 0 Posts
Feedback Score: 0 reviews
Send a message via AIM to Nally7.3Powerstroke
I think it might be the gasket your talking about. Im pulling the truck apart now so I will keep you all posted on anything I come across.
