Window Problems

I have a 96 crew cab XLT and my main drivers side switch board is messed up i can control my window and make the passenger one go down but other then that i cant do anthing with them, but each switch will work for the intended window, i was wonderin if my switch borad was messed up or wat???? thanks for any info


To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
--->Zach<---
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.


To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.

To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.

1996 CCLB, XLT PSD, 4x4,
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.

Auto, Autometer Guages, Matts Tunes, Stage 1's, AIS Water/Meth, Intake/Intercooler,
D66, gutted EBPV, Built Tran. dual napa Tran. Cooler and . . . More
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.

To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.

1995 Ranger XL 2.3L 2x4
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
More Photos -->
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
<--
YodersStrokin96 is offline
Sponsored Links
Advertisement

post #2 of 5 Old 06-08-2010, 07:42 AM
Compression Ignition Addict

zROCK's Avatar

Join Date: Aug 2009
Posts: 274
Thanks: 0
Thanked 0 Times in 0 Posts
Mentioned: 0 Post(s)
Quoted: 0 Post(s)
Feedback Score: 0 reviews
ok im sorta puzzled... i have read this several times and your saying they work for their intended pourpose. So what is the problem? hehe
zROCK is offline
post #3 of 5 Old 06-08-2010, 08:30 AM Thread Starter
Compression Ignition Addict

YodersStrokin96's Avatar

Join Date: Mar 2010
Location: New Riegel, Ohio
Posts: 1,679
Thanks: 0
Thanked 0 Times in 0 Posts
Mentioned: 0 Post(s)
Quoted: 0 Post(s)
Feedback Score: 0 reviews
lol my bad it was late ok ill try this (MAIN DRIVERS SWITCH's ----->drivers- works up and down, passenger- only down, Both rear windows-cant control at all) and all the passengers can control there windows by themselves so its just the Main one that i use with all four of switches i dont think is workin


To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
--->Zach<---
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.


To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.

To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.

1996 CCLB, XLT PSD, 4x4,
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.

Auto, Autometer Guages, Matts Tunes, Stage 1's, AIS Water/Meth, Intake/Intercooler,
D66, gutted EBPV, Built Tran. dual napa Tran. Cooler and . . . More
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.

To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.

1995 Ranger XL 2.3L 2x4
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
More Photos -->
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
<--
YodersStrokin96 is offline
post #4 of 5 Old 06-08-2010, 08:19 PM
Compression Ignition Addict

zROCK's Avatar

Join Date: Aug 2009
Posts: 274
Thanks: 0
Thanked 0 Times in 0 Posts
Mentioned: 0 Post(s)
Quoted: 0 Post(s)
Feedback Score: 0 reviews
Ahhh that makes alot more sence...hehe... The switch units are really easy to pull out and work on... Was having a similar problem and it turned out to be one of the contacts on the back where the wire connected had broken off. Didnt see it untill i tryed to pull the connections off the back ( I just fixed it by soldering a short wire onto teh switch termanel and a connector on the other end so i could disconect if needed)... First thing i would do is pull the switch pack out and try to get it in a position where you can see and work on the botom side easily... Then start working the switches and test light to see if you have power at both sides if the switch when you trigger the switch.. If you have power on both sides when you use the switch then problem lyes elseware... If you have no power out one side of switch then the probelm will be internal on the switch... If you are carefull and do it someware where you can work easily like the kitchen table you can pull the switch apart and clean the contacts with some verry fine sandpaper and alcohol... 90% of the time this will bring them back...

Of if you want to shoot in the dark you can buy a can of contact cleaner and spray the heck out of it and see it that is enough to get them working again.
zROCK is offline
post #5 of 5 Old 06-08-2010, 08:23 PM Thread Starter
Compression Ignition Addict

YodersStrokin96's Avatar

Join Date: Mar 2010
Location: New Riegel, Ohio
Posts: 1,679
Thanks: 0
Thanked 0 Times in 0 Posts
Mentioned: 0 Post(s)
Quoted: 0 Post(s)
Feedback Score: 0 reviews
alright i pulled it apart b4 when i was puttin new speakers in and just put some contact grease on the contact prol pull her in the shop tommorrow and have a closer look at it when i get back from gettin a load of calves, thanks ill see what i can get from there
