1992 F-250 Extended Cab Long Bed 460 to IDI Conversion

I've been looking into the idea of converting my 1992 F-250 Gasser to a Diesel, I needed to know if any other components will need to be changed over? or if I can just bolt it up? I plan to run a push button for the glowplugs and a shutdown switch to the Injection Pump. Will the 460 ZF5 trany bolt to the diesel or is there going to be problems there? I am not worried about the difference in gear ratios between the trannys that won't be a problem.

So any thoughts?

1993 Ford F-250 4x4 Reg. Cab with a Flat bed, Goodyear Wrangler 37s, Hays clutch, custom exhaust 4 inch exhaust to 5 inch stacks, building intake
Ranch_Ford is offline
post #2 of 7 Old 02-19-2010, 05:56 PM
Viking Heavy Diesel


Ryan Rønning's Avatar

Join Date: Nov 2007
Location: 34'.6264 -98.4192
Posts: 20,700
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks: 0
Thanked 1 Time in 1 Post
Feedback Score: 1 reviews
You will be best off to have a complete doner truck as there are always things you dont for see needing

Babe The Blue OX



2008 Ford F-450, TumbleWeed Headache Rack, B&W Gooseneck, 15% tinted windows, 120 Gal Transfer tank, Cobra 29 LX CB, 1200 watt converter, PIAA lights, Sinister goodies, S&B Intake and lots of running lights.

Quote:
Originally Posted by XPLOSIV View Post
Thanks. I'll give er a good wackin in the morning.
Ryan Rønning is offline
post #3 of 7 Old 02-19-2010, 06:12 PM
Serving Our Country!

cpayne6335's Avatar

Join Date: Oct 2009
Location: Germantown, Ohio
Posts: 441
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks: 0
Thanked 0 Times in 0 Posts
Feedback Score: 0 reviews
x2.... find a donor truck. there is a lot of stuff that you might need that will cost a bunch, that or find a good ol' 12v cummins.... but the tans adator plate might be a bit pricey, and engine mounts too. just have to look around and figure that out. I jsut got done working on a ide, and I must say, easy to work on. No valve covers to take off to replace GP's or sticks!!!!!

Looking for a FORD.
Chris
US Army, MOS:88M Ft. Lewis 17th Fires
cpayne6335 is offline
post #4 of 7 Old 02-20-2010, 07:22 AM
Emergency Services


Join Date: Apr 2008
Location: Beeville, TX
Posts: 1,489
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks: 1
Thanked 1 Time in 1 Post
Feedback Score: 0 reviews
No need to run a "shutdown switch", all you have to do is feed +12V to the fuel pump from a wire that is hot-in-run. Then your key switch will work like it's supposed to.

Your tachometer won't work with the gas version of the dash board. You could probably run an external tach. There is a set of wires on the fuel pump gear cover that reads the timing gear. I think you can splice into this for a tach.

Eli Benson - EMT, Ambulance Mechanic
----------
'08 F350 Dually KR - Spartan'd
'07 F250 CC SB 4x4 XLT - SCT /w Innovative Tunes
4 '09 & '10 E350 6.0l ambulances
1 '08 Duramax 6.6 (LMM) van ambulance
elibenson is offline
post #5 of 7 Old 02-22-2010, 12:12 PM
Member

joedaddy_43's Avatar

Join Date: Jul 2009
Location: lake county california, 2hrs north of san francisco
Posts: 79
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks: 0
Thanked 0 Times in 0 Posts
Feedback Score: 0 reviews
I'm in the process of doing the same conversion into an '88 is there any thing i need a heads up on?

1995 ford f350 crewcab longbed 7.3 powerstroke with the 5spd. 3" down pipe to 4" dump at the rear wheel. 4" lift an 36x12.5x16.5 wrangler r/t millitary -oz
joedaddy_43 is offline
post #6 of 7 Old 02-23-2010, 05:07 AM
Premium Member

ryandamo's Avatar

Join Date: Jun 2009
Location: Connecticut
Posts: 1,205
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks: 0
Thanked 0 Times in 0 Posts
Feedback Score: 0 reviews
the tranny wont bolt up directly from the gas engine, your going to have to drill some holes i beleive. Take a look at oilburners.net, there are quite a fw guys that know eveything about idi's over there.


2016 F450 6.7L XLT 4x4Dump, bone stock
1994 F250 7.3L XLT 4x4 ZF5 , Centurion, 4" Lift, 6637, Gulf Coast Bypass Filter, Big fuel tanks, dana 60 swap, No longer dually
1997 F350 7.3L XLT 4x4Dump, E4OD, 4 in exhaust, TS 6 position, 3/8 Trans line+external filter
2013 Scag Turf Tiger 61" 1.1L Caterpillar Diesel
1960 John Deere 440 Backhoe 2-53 detroit
ryandamo is offline
post #7 of 7 Old 02-24-2010, 09:05 AM Thread Starter
Powerstroke.org Rookie

Join Date: Mar 2009
Location: Arizona
Posts: 25
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks: 0
Thanked 0 Times in 0 Posts
Feedback Score: 0 reviews
Send a message via MSN to Ranch_Ford
I have a lot of the components left over from a truck I turned into a romper, so I pretty well have all the components I'd need from a donor truck. Like the Dash, Wiring and some odd ball components. I think I might do the conversion but it'll have to wait till I fix my main truck... Bent the pinion shaft off roading after I just rebuilt the rear end less that 3 months ago. A torch to cut the bent and warped pinion out and a few bucks later it's ready to be rebuilt again....

1993 Ford F-250 4x4 Reg. Cab with a Flat bed, Goodyear Wrangler 37s, Hays clutch, custom exhaust 4 inch exhaust to 5 inch stacks, building intake
Ranch_Ford is offline
